DC/DC Converters
Reliable and efficient DC/DC converters for electric vehicles, ranging from 48W to 6.6kW. DC/DC converters draw power from a bank of batteries or other high voltage DC power sources. They are typically used to supply power to accessories, lights, instruments, and on-board conversion. Datasheets included.
-
-
- DC/DC Converters
- 48W DC/DC Converter Wide-Range Input Series
- Green Watt Power's 48W wide-input range DC/DC modules are featured with extraordinary circuit designs, providing high-power density, high reliability, and high efficiency performance. The module is designed with excellent thermal management, anti-shock techniques, and super long life time. Ultra-Wide Input Voltage Operation Ultra High Reliability High Efficiency: Up to 94% All-Around Protections: OVP, SCP, OTP Natural Cooling On/Off Control RoHS…
- Read more Datasheet
DC/DC Module
Input: 22~160Vdc
Output: 24V @ 2A -
-
-
- DC/DC Converters
- 94W DC/DC Dual Output Converter Nano™ Series
- Green Watt Power’s 94W DC/DC power modules are designed with compact size, low cost, high efficiency, and high reliability. Featured with a fully sealed mechanical structure, this series offers solid, safe power conversions on electric bikes, electric motorcycles, and other DC/DC applications. Features: Wide Input Voltage: 36~80VDC Dual Output Voltage: 12VDC/7A and 5VDC/1A High Efficiency 94.0% Operating Case Temperature to…
- Read more Datasheet
DC/DC Module
Input Voltage 27~80Vdc
Output Voltage 12Vdc&5Vdc
Output Current 6A / 1.5A -
-
-
- DC/DC Converters
- 120W DC/DC Converter 13.2Vo Iron™ Series
- Green Watt Power’s 120W DC/DC power modules are designed with compact size, low cost, high efficiency, and high reliability. Featured with a fully sealed mechanical structure and 12V and 13.2V with up to 10A output, this series offers solid and safe power conversions on electrical bikes, electrical motorcycles, and other DC/DC applications. Wide Input Voltage: 30~60VDC Dual Output Voltage: 13.2VDC…
- Read more Datasheet
DC/DC Module
Input Voltage 30~60Vdc
Output Voltage 13.2V
Output Current 10A -
-
-
- DC/DC Converters
- 130W DC/DC Converter Dual Output Series
- Green Watt Power’s 130W DC/DC power modules are designed with compact size, low cost, high efficiency and high reliability. Featured with a non-isolated mechanical structure and 12V/10A 5V/2A dual output, this series offers solid and safe power conversions on electric bike, electric motorcycle and other DC/DC applications. Wide Input Voltage: 36~92Vdc Output Voltage: 12Vdc & 5Vdc High Reliability Ultra-High Efficiency:…
- Read more Datasheet
DC/DC Module
Input: 36~92Vdc
Output (dual): 12 & 5Vdc @10 & 2A -
-
-
- DC/DC Converters
- 200W DC/DC Converter
- Green Watt Power’s 200W DC/DC power modules are designed with compact size, low cost, high efficiency and high reliability. Featured with a fully sealed mechanical structure and 13.8V/14A output, this series offers solid and safe power conversions on electrical bike, electrical motorcycle and other DC/DC applications. Features: Wide Input Voltage: 40~90Vdc Output Voltage: 8Vdc High Efficiency up to 5% Operating…
- Read more Datasheet
DC/DC Module
Input: 40~90Vdc
Output: 13.8V @ 14A
Neon -
-
-
- DC/DC Converters
- 320 Watt EVD DC/DC Converter Wide Range Input Series
- Green Watt Power / Powerland’s 320W wide-input range DC/DC modules are featured with extraordinary circuit designs, providing high-power density, high reliability, and high efficiency performance. The module is designed with excellent thermal management, anti-shock techniques, and super long life time. Ultra-Wide Input Voltage Operation Ultra High Reliability High Efficiency: Up to 94% All-Around Protections: OVP, SCP, OTP Natural Cooling On/Off…
- Read more Datasheet
DC/DC Module
Input: 28~160Vdc
Output: 24V @ 13.3A -
-
-
- DC/DC Converters
- 300 Watt DC/DC Converter EVD Marble™ Series
- Green Watt Power’s 300-Watt Marble™ Series is a ruggedized DC-DC converter suitable for electric vehicles, marine, industrial, and other similar applications that draw power from a bank of batteries or other high DC voltages. It is used to supply power to accessories, lights, instruments, etc. Fully Isolated High Reliability High Efficiency 93% Parallel Connection (up to 10 units) Over Voltage…
- Read more Datasheet
DC/DC Module
Input: 30~130Vdc
Output: 13.5~27.5V @ 11~23A
Marble -
-
-
- DC/DC Converters
- 360W Multipurpose Caesar™ Series: DC/DC Converter
- This dual 360W Caesar Series can be used as either a constant voltage power supply or a DC/DC converter. It is designed with ultra-high efficiency and has a metal case enclosure. The extraordinary performances of low power dissipation and fan-less design provide high reliability and long lifetime. This series offer solid and safe power conversions for applications such as e-vehicles,…
- Read more Datasheet
Power Supply Module
Input Voltage Range: 100~400VDC or 90~264VAC
Multiple Outputs: 5V~48V @ 7.5~45A -
-
-
- DC/DC Converters
- 500 Watt EVD DC-DC Converter Marble™ Series 48V & 80V
- The 500-Watt EVD series is a ruggedized DC-DC converter suitable for electric vehicles, marine, industrial and other similar applications that draw power from a bank of batteries or other high DC voltages. It is used to supply power to accessories, lights, instruments, etc. Fully Isolated High Reliability High Efficiency 93% Parallel Connection (up to 10 units) Over Voltage Protection Short…
- Read more Datasheet
DC/DC Module
Input:30~130Vdc
Output:13.5~27.5V @18.5~38A -
-
-
- DC/DC Converters
- 600~1000 Watt DC/DC Converter EVD Series
- Optimized for EV On-Board Systems High input and wide range voltage 280~420V Fully Isolated High Efficiency up to 96% Parallel Connection Available Over Voltage Protection Short Circuit Protection Over Temperature Protection Enable/Remote On/Off IP67 Enclosure, fully potted CAN Communications Built-in EMI Filter, Comply with EMC Standard CISPR25/ GB/T18655 Class 3
- Read more Datasheet
DC/DC Module
Input:280~420 Vdc
Output:14V@43~72A
-
-
![2500W [Coming Soon]](https://greenwattpower.com/wp-content/uploads/2500W-DCDC-300x300.jpg)
-
- DC/DC Converters
- 2500W [Coming Soon]
- Read more
DC/DC Isolated
Input Voltage 200-470Vdc
Output Voltage 9-16Vdc
Output Current 175A
Atlas -
-
-
- DC/DC Converters
- 3kW and 4.2kW High to Low Voltage DC/DC Converter Falcon™ Series
- Green Watt/Powerland’s 3-4.2kW Falcon Series DC/DC power supplies for 27.5V and 50.4V output EV systems with Li-Ion batteries are designed with extended protection functions, next-generation semiconductor power devices, and superior thermal management. It is the industry’s first DC/DC power supply design covering the full input voltage range perfectly fitting a wide variety of on-board electric vehicle applications, for example, air…
- Read more Datasheet
3000~4200W
DC/DC Module
Input: 280~880 Vdc
Output: 27.5V @110A~146A
Output: 48V @62.5A~83A -
-
-
- DC/DC Converters
- 3000 Watt Bi-directional DC/DC Converter EVDB Series (3kW)
- Green Watt Power / Powerland’s 3kW bi-directional DC/DC power supply is designed with extended protection functions, the next-generation semiconductor power devices, and the extraordinary thermal management. The bi-directional energy flow with CAN communication interface makes the converter feasible for a wide variety of electric vehicles. Features DC/DC Bidirectional Energy Flow High Efficiency Built-in All-Around Protections EMC Comply with UN ECE…
- Read more Datasheet
Bi-directional DC/DC Module
Input: 270~420Vdc/13V (Typ.)
Output: 13V@143A/380Vdc (Typ.)@11A
Orion -
| SERIES NAME | POWER WATTS | VIN RANGE VDC | OUTPUT VDC | OUTPUT AMPS | COMM (CAN) | OPERATING TEMP. °C | IP RATING | SIZE (LxWxH) MM | GWP MODEL | URL-GWP |
|---|---|---|---|---|---|---|---|---|---|---|
| Granite | 48 | 22~160 | 24 | 2 | N/A | -40~85oC | IP65 | 100x90x27 | EVD-91-48-24 | See product |
| Nano Non-isol. | 94 | 36~80 | 12 & 5 | 6 & 1.5 | N/A | -33~70oC | IP67 | 74.6x32.7x24 | EVD-54-94-D12-5-MET | See Product |
| Iron Non-Isol. | 125 | 36~72 | 12 & 5 | 10 & 2 | N/A | -20~40oC | IP65 | 89.5x69x40.1 | EVD-60-125-D12-5 | See Product |
| Iron Non-Isol. | 130 | 36~92 | 12 & 5 | 10 & 2 | N/A | -20~60oC | IP66 | 59x58x21.5 | EVD-60-130-D12-5 | See Product |
| Neon Non-isol. | 200 | 40-90 | 13.8 | 14 | N/A | -20°~60oC | IP65 | 100x90x27 | EVD-60-200-13 | See Product |
| Caesar | 230 | 100~400 (90~264AC) | 5 | 45 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-05-XY | See Product |
| Caesar | 260 | 100~400 (90~264AC) | 12 | 21.5 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-12-XY | See Product |
| Caesar | 260 | 100~400 (90~264AC) | 15 | 17.3 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-15-XY | See Product |
| Marble | 300 | 30-65 | 13.5 | 23 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-48-300-13 | See Product |
| Marble | 300 | 30-65 | 13.5 | 23 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-48-300-13F | See Product |
| Marble | 300 | 50-126 | 13.5 | 23 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-300-13 | See Product |
| Marble | 300 | 50-130 | 13.5 | 23 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-300-13F | See Product |
| Marble | 300 | 50-130 | 24 | 12.5 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-300-24F | See Product |
| Marble | 300 | 50-130 | 27.5 | 11 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-300-27F | See Product |
| Caesar | 320 | 100~400 (90~264AC) | 20 | 16 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-20-XY | See Product |
| Granite | 320 | 28~160 | 24 | 12.5 | N/A | -40~85oC | IP65 | 100x90x27 | EVD-94-320-24 | See Product |
| Caesar | 320 | 100~400 (90~264AC) | 24 | 13.3 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-24-XY | See Product |
| Caesar | 320 | 100~400 (90~264AC) | 28 | 11.4 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-28-XY | See Product |
| Caesar | 320 | 100~400 (90~264AC) | 36 | 8.9 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-36-XY | See Product |
| Caesar | 360 | 100~400 (90~264AC) | 48 | 7.5 | N/A | -40~55oC | N/A | 182x48.5x26 | EVD-250-360-48-XY | See Product |
| Marble | 500 | 30-65 | 13.5 | 38 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-48-500-13 | See Product |
| Marble | 500 | 30-65 | 13.5 | 38 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-48-500-13F | See Product |
| Marble | 500 | 50-126 | 13.5 | 38 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-500-13 | See Product |
| Marble | 500 | 50-130 | 13.5 | 38 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-500-13F | See Product |
| Marble | 500 | 50-130 | 24 | 20 | N/A | -40~85oC | IP65 | 190x76x45 | EVD-80-500-24F | See Product |
| Marble | 500 | 50-130 | 27.5 | 18.5 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-500-27F | See Product |
| Orion | 2,500 | 300 ~ 410 /28~58.4 | 28 ~ 58.4 /300 ~ 410 | 50/7.5 | CAN | -40 ~ 60oC | N/A | 273x101x58.3 | Coming Soon |
|
| Orion | 4,500 | 300 ~ 450 /28 ~ 58.4 | 28 ~ 58.4 /300 ~ 450 | 92/12 | CAN | -40 ~ 60oC | N/A | 268x188x52 | Coming Soon |
|
| Nova | 3,300 | 28~96dc | 40-56 | 6~120 | CAN | -40~70oC | N/A | 114.6x89.5x18 | Coming Soon |
|
| Nova | 3,300 | 23~60dc | 40~58 | 6~132 | CAN | -40~60oC | N/A | 114.6x83.5x18 | Coming Soon |
|
| Marble | 500 | 50-130 | 27.5 | 18.5 | N/A | -40~85oC | IP67 | 190x76x45 | EVD-80-500-27 | See Product |
| Nova | 6,600 | 50~300 | 300~450 | 0~22 | CAN | -40~60oC | N/A | 114.6x83.5x18 | Coming Soon |
|
| Nova | 6,600 | 50~300 | 300~450 | 0~22 | CAN | -40~60oC | N/A | 114.6x83.5x18 | Coming Soon |
|
| Leopard | 600 | 280~420 | 14 | 43 | CAN | -40~85oC | IP67 | 164x109x31 | PLD600-EVDBT | See Product |
| Leopard | 1,000 | 280~420 | 14 | 72 | CAN | -40~85oC | IP67 | 164x109x31 | PLD1000-EVDBT | See Product |
| Atlas | 2,500 | 200~470 | 9~16 | 175 | CAN | -40~70oC | IP67 | 175x120x30 | EVD-350-2500-13 | See Product |
| Falcon | 3,000 | 280~880 | 27.5 | 110 | CAN | -40~85oC | IP67 | 258.5x164x54.5 | EVD-590-3000A-28 | See Product |
| Falcon | 3,000 | 280~880 | 48 | 62.5 | CAN | -40~85oC | IP54 | 258.5x164x54.5 | EVD-590-3000-48-DP | See Product |
| Nova | 3,300 | 23~60 | 40~60 | 6~90 | CAN | -40~60oC | N/A | 114.6x83.5x18 | PLD3300-20FC01-48B | See Product |
| Falcon | 4,200 | 490~900 | 50.4 | 84 | CAN | -40~85oC | IP67 | 258.5x164x54.5 | EVD-590-4200A-50 | See Product |
